MAXCO 120-2RB MAX120-2R-10
  1. pin-int

MAXCO 120-2RB MAX120-2R-10

Maxco Chain 120-2RB Riveted Standard Roller Chain, 10 ft OAL, 1-1/2 in Pitch, 7/8 in Dia x 1 in W Roller

  • Manufacturer: SENQCIA MAXCO, Ltd.
  • Brand Name: MAXCO
  • Part Number: MAX120-2R-10
  • MPN: 120-2RB
  • UPC: 821002004298
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

SENQCIA Inspire Series™ SBR® riveted roller chain is manufactured in Japan in accordance with the ASME/ANSI B29.1 American roller chain standard. These solid bushing/solid roller chains offer exceptional performance and long life in a wide variety of applications. Chain pins are produced from a special boron steel to improve strength. Solid cold forged bushings and a patented pin treatment extend chain wear life and greatly reduce break-in wear. Packaged chains are pre-lubricated with high quality wax-type grease and come with a necessary connecting link to join the ends. Offset links (used to shorten or lengthen a chain strand by 1 pitch) are also available and sold separately. This chain is packaged in a 10 ft box.

Maxco Chain Roller Chain, Riveted Standard, 1-1/2 in Pitch, 0.437 in Pin Dia, 3.74 in Pin Length, 7/8 in Roller Dia, 1 in Roller Width, 1.382 in Plate Height, 0.188 in Plate Thickness, 80 Links, 2 Strands, 78000 lb Average Tensile, 10 ft Overall Length

Number of Links      :      80
Number of Strands      :      2
Overall Length      :      10 ft
Pin Diameter      :      0.437 in
Pin Length      :      3.74 in
Pitch      :      1-1/2 in
Plate Height      :      1.382 in
Plate Thickness      :      0.188 in
Roller Diameter      :      0.875 in
Roller Width      :      1 in
Tensile Strength      :      78000 lb Average
Type      :      Riveted Standard
  • Higher rated working loads
  • Improved wear and abrasion resistance
  • New boron steel pins for most sizes that increase strength and improve ductility
  • Proprietary stainless steel blast for link plates and rollers to protect against rust
  • Unique triple zone hardness on chain pins
  • Wide waist link plates
  • Redesigned high strength connecting link with flat style closing plates
  • Superior special blend pre-lubricant
