Bower® LM67048/LM67010 NTNSET6
Bower® LM67048/LM67010 J Series Round Bore Tapered Roller Bearing, 31.75 mm Dia Bore, 59.131 mm OD, 1 Row, 16.764 mm W, 41000 N Load
- Manufacturer: NTN
- Brand Name: Bower®
- Part Number: NTNSET6
- MPN: LM67048/LM67010
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Bower LM67048/LM67010 J Series Round Bore Tapered Roller Bearing features 31.75 mm bore, 59.131 mm OD, and 16.764 mm width and single-row and open design. Key specifications include Case Carburized Steel bearing, 34500 N dynamic and 41000 N static load ratings, and temperature -40 to 120 deg C. Tapered roller geometry is suited to combined radial and axial loading when correctly mounted with the specified mating component.
Bower® Tapered Roller Bearing, Round Bore, Series: J Series, 31.75 mm Bore Dia, 59.131 mm Outside Dia, 1 Row, 16.764 mm W, Open Closure, 41000 N, Case Carburized Steel Bearing, -40 to 120 deg C
| Bearing Material | : | Case Carburized Steel |
| Bore Diameter | : | 31.75 mm |
| Closure Type | : | Open |
| Load Capacity | : | 41000 N |
| Number of Rows | : | 1 |
| Outside Diameter | : | 59.131 mm |
| Series | : | J Series |
| Temperature Rating | : | -40 to 120 deg C |
| Type | : | Round Bore |
| Width | : | 16.764 mm |
- Product type: Tapered Roller Bearing
- Dimensions: 31.75 mm bore x 59.131 mm outside diameter x 16.764 mm width
- Design: Single row; open
- Construction: Case-carburized steel bearing
- Load ratings: 34,500 N dynamic / 41,000 N static
- Operating temperature: -40 to 120 °C
- Oil hole: None
- Precision class: 2
