Sealmaster® 705479 MORSFT16T
Sealmaster® 705479 SFT Non-Expansion Standard Duty Flange Mount Ball Bearing Unit, 1 in Dia Bore, 3-57/64 in L Bolt Center-to-Center, 2-Bolt Flange Mount, 2-3/4 in OAL/Dia
- Manufacturer: Regal Rexnord
- Brand Name: Sealmaster®
- Part Number: MORSFT16T
- Alt Part Number: SFT-16T
- MPN: 705479
- UPC: 662461030349
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at EVANSVILLE, IN
-
Check Availability at All Branches
- Sold As: 1/EA
-
Price:
Sealmaster® gold mounted ball bearings feature a wide outer race insert bearing with land riding metallic retainer. The black oxide treated bearing steel insert features an exclusive lock pin and dimple system providing a direct path for lubrication into the bearing and prevents outer ring rotation within the housing. Shaft lock is achieved by either setscrew or Skwezloc® concentric locking collar. The felt seal with flinger provide a good balance between contaminant entry, GoldPlex® HP grease loss and friction.
Sealmaster® Flange Mount Ball Bearing Unit, Non-Expansion Standard Duty, Series: SFT, 1 in Bore, 3-57/64 in Bolt Center-to-Center Length, 2-Bolt Flange Mounting, 2-3/4 in Overall Length/Diameter, 1-1/2 in Overall Depth, 4-7/8 in Overall Height, Skwezloc® Locking Device, Steel Bearing, Felt Seal, 2801 lb Dynamic/1651 lb Static Load, 9000 rpm Maximum, -20 to 220 deg F, Uncoated
| Bearing Material | : | Steel |
| Bolt Center-to-Center Length | : | 3-57/64 in |
| Bore Diameter | : | 1 in |
| Finish | : | Uncoated |
| Flange Mounting Type | : | 2-Bolt |
| Load Capacity | : | 2801 lb Dynamic/1651 lb Static |
| Locking Device | : | Skwezloc® Locking |
| Maximum Speed | : | 9000 rpm |
| Overall Depth | : | 1-1/2 in |
| Overall Height | : | 4-7/8 in |
| Overall Length/Diameter | : | 2-3/4 in |
| Seal Material | : | Felt |
| Series | : | SFT |
| Temperature Rating | : | -20 to 220 deg F |
| Type | : | Non-Expansion Standard Duty |
- Wide outer ring
- The felt seal with flinger provides a tight labyrinth seal which retains lubrication and acts as a filter to exclude contamination
- Zone hardened inner race
- 52100 black oxide coated steel bearing
- Stamped steel rubber mounted flange
- Powder coated epoxy cast iron housing with extended inner ring bearings
- Skwezloc concentric locking for near perfect concentricity
- Unique land riding retainer design provides superior pocket clearance that allows for 360 deg grease circulation around the rolling elements resulting in better retained and utilized lubrication
- Sealmaster exclusive lock pin and dimple for direct lubrication and anti-rotation
