Rex® 10415360 REXMBR5307
Rex® 10415360 5000 Fixed Heavy Duty Flanged Cartridge Block Spherical Roller Bearing, 3-7/16 in Dia Bore, 6-3/32 in L Bolt Center-to-Center, 4-5/16 in Dia Bolt Circle, 4-Bolt Round Flange Mount, 10-1/4 in OAL/Dia
- Manufacturer: Regal Rexnord
- Brand Name: Rex®
- Part Number: REXMBR5307
- MPN: 10415360
- UPC: 698210632878
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
Rex® Bearings represent the continuation of 80 years of bearing technology and experience. This design allows the inner race to misalign freely in any direction up to 4 deg of total misalignment. By design, Rex® Bearings accept both radial and thrust loads under static, oscillatory or dynamic conditions. The load is taken on the roller raceways, not the roller ends. This means that when thrust is loaded up to their allowable limit, Rex® Bearings do not exhibit roller end wear.
Rex® Flanged Cartridge Block Spherical Roller Bearing, Fixed Heavy Duty, Series: 5000, 3-7/16 in Bore, 6-3/32 in Bolt Center-to-Center Length, 4-5/16 in Diameter Bolt Circle, 4-Bolt Round Flange Mounting, 10-1/4 in Overall Length/Diameter, 5-5/16 in Overall Depth, Double Set Screw Collar Locking Device, Cast Iron Bearing, Elastomer Seal, 84330 lb Dynamic/90700 lb Static Load, 1400 rpm Maximum, 225 deg F, Powder Coated
| Bearing Material | : | Cast Iron |
| Bolt Center-to-Center Length | : | 6-3/32 in |
| Bolt Circle Diameter | : | 4-5/16 in |
| Bore Diameter | : | 3-7/16 in |
| Finish | : | Powder Coated |
| Flange Mounting Type | : | 4-Bolt Round |
| Load Capacity | : | 84330 lb Dynamic/90700 lb Static |
| Locking Device | : | Double Set Screw Collar |
| Maximum Speed | : | 1400 rpm |
| Overall Depth | : | 5-5/16 in |
| Overall Length/Diameter | : | 10-1/4 in |
| Seal Material | : | Elastomer |
| Series | : | 5000 |
| Temperature Rating | : | 225 deg F |
| Type | : | Fixed Heavy Duty |
- Easy bearing clearance adjustment
- Pre-lubricated with standard grease for normal operation
- Super-finished raceways provide a cool running and quiet, high-speed and high-load capacity bearing
- Shaft ready and rugged housing
- Type M spring loaded heavy contact seal
- Factory set clearance and lubrication
