MAXCO 50-3RB MAX50-3R-10
  1. pin-int

MAXCO 50-3RB MAX50-3R-10

Maxco Chain 50-3RB Riveted Standard Roller Chain, 10 ft OAL, 5/8 in Pitch, 0.4 in Dia x 3/8 in W Roller, Carbon Steel

  • Manufacturer: SENQCIA MAXCO, Ltd.
  • Brand Name: MAXCO
  • Part Number: MAX50-3R-10
  • MPN: 50-3RB
  • UPC: 821002020267
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

SENQCIA Inspire Series™ SBR® riveted roller chain is manufactured in Japan in accordance with the ASME/ANSI B29.1 American roller chain standard. These solid bushing/solid roller chains offer exceptional performance and long life in a wide variety of applications. Chain pins are produced from a special boron steel to improve strength. Solid cold forged bushings and a patented pin treatment extend chain wear life and greatly reduce break-in wear. Packaged chains are pre-lubricated with high quality wax-type grease and come with a necessary connecting link to join the ends. Offset links (used to shorten or lengthen a chain strand by 1 pitch) are also available and sold separately. This chain is packaged in a 10 ft box.

Maxco Chain Roller Chain, Riveted Standard, 5/8 in Pitch, 0.2 in Pin Dia, 2.23 in Pin Length, 0.4 in Roller Dia, 3/8 in Roller Width, 0.575 in Plate Height, 0.08 in Plate Thickness, 192 Links, 3 Strands, 21600 lb Average Tensile, 10 ft Overall Length, Carbon Steel

Material      :      Carbon Steel
Number of Links      :      192
Number of Strands      :      3
Overall Length      :      10 ft
Pin Diameter      :      0.2 in
Pin Length      :      2.23 in
Pitch      :      5/8 in
Plate Height      :      0.575 in
Plate Thickness      :      0.08 in
Roller Diameter      :      0.4 in
Roller Width      :      3/8 in
Tensile Strength      :      21600 lb Average
Type      :      Riveted Standard
  • Higher rated working loads
  • Improved wear and abrasion resistance
  • New boron steel pins for most sizes that increase strength and improve ductility
  • Proprietary stainless steel blast for link plates and rollers to protect against rust
  • Unique triple zone hardness on chain pins
  • Wide waist link plates
  • Redesigned high strength connecting link with flat style closing plates
  • Superior special blend pre-lubricant
