Martin 80BS20HT 2 MAR80BS20HT2
Martin Saber Tooth® 80BS20HT 2 Bored-to-Size Type BS Single Pitch Roller Chain Sprocket With Hardened Teeth and Keyway, 2 in Dia Bore, 6.914 in OD, #80 Chain, 20 Teeth, 1 in Pitch, Steel
- Manufacturer: Martin Sprocket & Gear
- Brand Name: Martin
- Part Number: MAR80BS20HT2
- MPN: 80BS20HT 2
- UPC: 697950164359
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
These finished bore sprockets are hardened, shaft ready and come complete with keyways and setscrews. The keyways are on center line of the tooth. Bored to size sprockets with 1/2 in bores and smaller are stocked with (2) setscrews only.
Martin Saber Tooth® Single Pitch Roller Chain Sprocket, Bored-to-Size Type BS, 2 in Bore Dia, 6.914 in Outside Dia, #80 Chain, 20 Teeth, 1 in Pitch, 6.393 in, 4-1/4 in Hub Dia, 1/2-13 x 1/2 in Screw, 1/2 x 1/4 in Keyway, 1-1/2 in Length Through Bore, Steel
| Bore Diameter | : | 2 in |
| Chain Size | : | #80 |
| Hub Diameter | : | 4-1/4 in |
| Keyway Size | : | 1/2 x 1/4 in |
| Length Through Bore | : | 1-1/2 in |
| Material | : | Steel |
| Number of Teeth | : | 20 |
| Outside Diameter | : | 6.914 in |
| Pitch Diameter | : | 6.393 in |
| Pitch | : | 1 in |
| Screw Size | : | 1/2-13 x 1/2 in |
| Type | : | Bored-to-Size Type BS |
- Keyway is on center line of tooth
- Stock finished bores
- Precise machining and processes ensure consistent finish and high quality
- Bores are concentric to pitch line, minimizing run out
- 2 set screws keyed on centerline of tooth
