IPTCI Bearings UC204-20MM IPTUC204-20MM
IPTCI Bearings UC204-20MM Silver Normal Duty Ball Bearing Insert, 20 mm Dia Bore, 47 mm OD, 31 mm W, 12800 lb Dynamic/6600 lb Static Load
- Manufacturer: Solve Industrial Motion Group
- Brand Name: IPTCI Bearings
- Part Number: IPTUC204-20MM
- Alt Part Number: 2101032147
- MPN: UC204-20MM
- UPC: 080067561309
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
IPTCI Bearings Ball Bearing Insert, Normal Duty, Series: Silver UC 200, 20 mm Bore Dia, 47 mm Outside Dia, 31 mm Width, 12800 lb Dynamic/6600 lb Static, 100CR6 Steel Bearing, Steel Cage, 7450 rpm Maximum
| Bearing Material | : | 100CR6 Steel |
| Bore Diameter | : | 20 mm |
| Cage Material | : | Steel |
| Load Capacity | : | 12800 lb Dynamic/6600 lb Static |
| Maximum Speed | : | 7450 rpm |
| Outside Diameter | : | 47 mm |
| Series | : | Silver UC 200 |
| Type | : | Normal Duty |
| Width | : | 31 mm |
- Set screw locking
- Wide inner ring
- Steel retainer
Specification Sheet
