Browning® 1174168 BROD40P24
  1. pin-int

Browning® 1174168 BROD40P24

Browning® 1174168 Double Strand Type 12 Roller Chain Sprocket With Hardened Teeth, 1/2 to 1-3/4 in Dia Bore, 4.098 in OD, 40 Chain, 24 Teeth, 1/2 in Pitch, Steel

  • Manufacturer: Regal Rexnord
  • Brand Name: Browning®
  • Part Number: BROD40P24
  • Alt Part Number: D40P24
  • MPN: 1174168
  • UPC: 662289238835
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.

Browning® Roller Chain Sprocket, Double Strand Type 12, 1/2 to 1-3/4 in Bore, 4.098 in OD, 40 Chain, 24 Teeth, 3.831 in Pitch Diameter, 3 in Diameter Hub, 2.1427 in Length Through Bore, Steel

Bore Diameter      :      1/2 to 1-3/4 in
Chain Size      :      40
Hub Diameter      :      3 in
Length Through Bore      :      2.1427 in
Material      :      Steel
Number of Teeth      :      24
Outside Diameter      :      4.098 in
Pitch Diameter      :      3.831 in
Type      :      Double Strand Type 12
  • This product has the Browning® exclusive twice the life guarantee
  • Hardened teeth at no extra cost, drives sizes up to 30 teeth on 35 through 160 chain
  • External key, higher torque capacity, aligns bolt holes
  • Provides key to key drive
  • Double split barrel, improved clamping
  • Solid flange, true concentricity, easy installation
  • Longer barrel, better support on the shaft
  • For use with 1/2 in pitch ANSI chain
  • Easy installation and removal
