Browning® 1011253 BRO4B154R
Browning® 1011253 Type 13 Arm Multiple Sheave, 1.13 to 3.75 in Split Taper Bore, 15-3/4 in OD, 4 Grooves, 15.2 in (A)/15.7 in (B) Dia Pitch, 3-1/4 in W Face
- Manufacturer: Regal Rexnord
- Brand Name: Browning®
- Part Number: BRO4B154R
- Alt Part Number: 4B154R
- MPN: 1011253
- UPC: 662289310968
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Browning® offers an extensive multi-groove sheave offering. This includes Browning® Split-Taper® and QD® bushing designs. This means maximum economy and versatility for your application. Truly the right drive every time our exclusive B5V® sheaves have a patented design that offers 5V horsepower in the economy of a B section sheave. B5V® sheaves serve 90% of all applications from 10 to 150 hp. This can reduce cost up to 40% over traditional designs.
Browning® Multiple Sheave, Type 13 Arm, Split Taper Bore, 1.13 to 3.75 in Bore, 15-3/4 in OD, 15.2 in (A)/15.7 in (B) Pitch Diameter, 4 Grooves, 3-1/4 in Face Width, R1 Bushing, 3-25/32 in Overall Length, For Use With: GripBelt® A and B Cross Section V-Belt, Cast Iron
| Bore Diameter | : | 1.13 to 3.75 in |
| Bore Type | : | Split Taper |
| Bushing Type | : | R1 |
| Face Width | : | 3-1/4 in |
| Material | : | Cast Iron |
| Number of Grooves | : | 4 |
| Outside Diameter | : | 15-3/4 in |
| Overall Length | : | 3-25/32 in |
| Pitch Diameter | : | 15.2 in (A)/15.7 in (B) |
| Suitable For Use With | : | GripBelt® A and B Cross Section V-Belt |
| Type | : | Type 13 Arm |
- Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub
- Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers
- Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible
