Timken® QMFL09J111SM QMBQMFL09J111SM
Timken® QMFL09J111SM Heavy Duty Non-Expansion Cylindrical Bore Spherical Roller Bearing Unit, 1-11/16 in Dia Bore, 3.89 in L Bolt Center-to-Center, 5-1/2 in Dia Bolt Circle, 4-Bolt Square Flange Mount, 5.38 in OAL/Dia
- Manufacturer: Timken
- Brand Name: Timken®
- Part Number: QMBQMFL09J111SM
- MPN: QMFL09J111SM
- UPC: 883450162890
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Timken® solid block mounted spherical roller bearings (housed units) feature high-performance, low operating temperature Timken® double row spherical roller bearings, cast steel housings, unique locking and sealing design options to offer protection against contaminants in the harshest environments. Timken® spherical roller bearings are ideal for handling high radial loads.
Timken®, QMFL09J111SM, Spherical Roller Bearing Unit, Heavy Duty Non-Expansion Cylindrical Bore, 1-11/16 in Bore, 3.89 in Bolt Center-to-Center Length, 5-1/2 in Diameter Bolt Circle, 4-Bolt Square Flange Mounting, 5.38 in Overall Length/Diameter, 3.13 in Overall Depth, 5.38 in Overall Height, Eccentric Locking Device, Steel Bearing, Nitrile Rubber Seal, 24500 lb Dynamic/24200 lb Static Load, 2700 rpm Maximum, -40 to 250 deg F, Powder Coated
| Bearing Material | : | Steel |
| Bolt Center-to-Center Length | : | 3.89 in |
| Bolt Circle Diameter | : | 5-1/2 in |
| Bore Diameter | : | 1-11/16 in |
| Finish | : | Powder Coated |
| Flange Mounting Type | : | 4-Bolt Square |
| Load Capacity | : | 24500 lb Dynamic/24200 lb Static |
| Locking Device | : | Eccentric |
| Maximum Speed | : | 2700 rpm |
| Overall Depth | : | 3.13 in |
| Overall Height | : | 5.38 in |
| Overall Length/Diameter | : | 5.38 in |
| Seal Material | : | Nitrile Rubber |
| Temperature Rating | : | -40 to 250 deg F |
| Type | : | Heavy Duty Non-Expansion Cylindrical Bore |
- Reduced eccentric offset locking collar results in a secure shaft lock that is designed not to release from a properly prepared shaft
- Suitable for reversing applications
- Triple-lip contacting, self-purging nitrile rubber seal is excellent in moist and dirty applications, chemical and corrosion resistant
- Double row bearing
- Cast steel housing
- Open end type
- Solid block housing
- Do not operate at bearing temperatures above 250 deg F
