Timken H305 adapter sleeve for a 20 mm cylindrical shaft. Used to mount a compatible tapered-bore bearing. Nominal sleeve length: 29 mm. Nominal supplied locknut outside diameter: 38 mm. Thread size: M25 x 1.5. The assembly includes a sleeve, locknut and lockwasher. Components: H305 sleeve; KM5 locknut; MB5 lockwasher.
| Brand Name | : | Timken |
| Outside Diameter | : | 38 mm |
| Overall Length | : | 29 mm |
| Series | : | H3 |
| Shaft Diameter | : | 20 mm |
| Thread Size | : | M25 x 1.5 |
| Type | : | Adapter Assembly |
- Safe and effective tapered bore bearing assembly
- Other dimensions may be available, consult your Timken sales representative
