Timken® 68514432332 LOV68514432332

Timken® 68514432332 Standard Jaw Coupling Hub, L090 Coupling, 15/16 in Dia Bore, 0.82 in L Through Bore, 0.250 to 1 in Dia Hub, Sintered Iron

  • Manufacturer: Timken
  • Brand Name: Timken®
  • Part Number: LOV68514432332
  • MPN: 68514432332
  • UPC: 685144323323
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Timken®, 68514432332, Jaw Coupling Hub, Standard, L090 Coupling, 15/16 in Bore, 0.250 to 1 in Diameter Hub, 1.32 in Hub Length, 1/4 in W x 1/8 in D Keyway, 9000 rpm Maximum, 0.82 in Length Through Bore, Sintered Iron

Bore Diameter      :      15/16 in
Coupling Size      :      L090
Hub Diameter      :      0.25 to 1 in
Hub Length      :      1.32 in
Keyway Size      :      1/4 in W x 1/8 in D
Length Through Bore      :      0.82 in
Material      :      Sintered Iron
Maximum Speed      :      9000 rpm
Type      :      Standard
  • Fail safe - will still perform if elastomer fails
  • No metal to metal contact
  • Resistant to oil, dirt, sand, moisture and grease
  • More than 850000 combinations of bore sizes
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_68514411512_Catalog.pdf
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_68514411512_Installation_Manual.pdf
