Timken® 203PPG21Z3FS50387K TIM203PPG21
Timken® 203PPG21Z3FS50387K 200 Light Straight Bore Deep Groove Radial Ball Bearing, 17 mm Dia Bore, 40 mm Dia Outside, 1 Rows, 12 mm W, 2380 lb Dynamic/1070 lb Static Load
- Manufacturer: Timken
- Brand Name: Timken®
- Part Number: TIM203PPG21
- Alt Part Number: 100161554
- MPN: 203PPG21Z3FS50387K
- UPC: 087796301467
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Timken® supplies a full range of product in the world's most popular design series. Timken® deep groove ball bearings deliver reliable performance in a wide range of applications and conditions.
Timken®, 203PPG21Z3FS50387K, Deep Groove Radial Ball Bearing, Light Straight Bore, Series: 200, 17 mm Bore, 40 mm OD, 1 Rows, 12 mm Width, Dual Pop-In Seal Closure, 2380 lb Dynamic/1070 lb Static Load, Cold Rolled Steel Cage, 17647.05 rpm Grease/17647.05 rpm Oil Maximum, -50 to 120 deg C
| Bearing Material | : | Steel |
| Bore Diameter | : | 17 mm |
| Cage Material | : | Cold Rolled Steel |
| Closure Type | : | Dual Pop-In Seal |
| Load Capacity | : | 2380 lb Dynamic/1070 lb Static |
| Maximum Speed | : | 17647.05 rpm Grease/17647.05 rpm Oil |
| Number of Rows | : | 1 |
| Outside Diameter | : | 40 mm |
| Series | : | 200 |
| Temperature Rating | : | -50 to 120 deg C |
| Type | : | Light Straight Bore |
| Width | : | 12 mm |
- Super finished raceways
- Quiet operation
- Light 200 series have a close dimensional balance between bore, outside diameter and width making them well suited for applications with light to medium loads and high speed
