Thomson® SB24 THOSB24
Thomson® 60 Case® LinearRace® SB24 Standard Type SB Shaft Support Block, 1-1/2 in Dia Shaft, 4-3/4 in L x 1-1/4 in W x 3-1/2 in H
- Manufacturer: Thomson Industries
- Brand Name: Thomson®
- Part Number: THOSB24
- MPN: SB24
- UPC: 662486101673
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
Shaft support blocks are used for end or intermittent support where loads are light and deflection between supports is not a problem. Unlike shaft support rails, blocks do not permit longitudinal passage of open-type Ball Bushing® bearings. Type SB shaft support blocks enable clamping of shafts and eliminate the need for bolts, to maintain shaft position. Shimming is suggested for high-precision applications to eliminate the effect of variations in surface of base or manufacturing tolerances between supports.
Thomson® 60 Case® LinearRace® Shaft Support Block, Standard Type SB, 1-1/2 in Shaft Diameter, 1-1/4 in Width, 3-1/2 in Height, 4-3/4 in Length, For Use With: RoundRail™ 1BA/1NA End-Supported Linear Guide, Malleable Iron, Painted
| Finish | : | Painted |
| Height | : | 3-1/2 in |
| Length | : | 4-3/4 in |
| Material | : | Malleable Iron |
| Shaft Diameter | : | 1-1/2 in |
| Suitable For Use With | : | RoundRail™ 1BA/1NA End-Supported Linear Guide |
| Type | : | Standard Type SB |
| Width | : | 1-1/4 in |
- Easily secured with two mounting bolts
- Protected by corrosion resistant coating
- Lightweight, high-strength aluminum alloy construction
