Thomson® FNYBUTFB16LS THOFNYBUTFB16LS
Thomson® FluoroNyliner® Bushing® FNYBUTFB16LS FB Series Closed Twin Linear Bearing Flanged Pillow Block, 1 in Dia Shaft, 2-1/4 in OD, 2-3/4 in L x 5.33 in W x 2-3/4 in H
- Manufacturer: Thomson Industries
- Brand Name: Thomson®
- Part Number: THOFNYBUTFB16LS
- MPN: FNYBUTFB16LS
- UPC: 662486108702
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
The FluoroNyliner® Bushing® Bearing is a self-lubricating, plain-type bearing. Its large contact surface area gives it excellent performance in high vibration or impact applications, while its simplified design allows it to run in highly contaminated environments. The FluoroNyliner® can be used with unhardened, highly corrosion resistant shafting, making it ideal for wash-down or submerged environments.
Thomson® FluoroNyliner® Bushing® Linear Bearing Flanged Pillow Block, Closed Twin, Series: FB Series, 1 in Shaft Dia, 2-1/4 in Outside Dia, 2-3/4 in Height, 2-3/4 in Length, 5.33 in Width, 7000 lb Static, Steel Bearing, 550 deg F
| Bearing Material | : | Steel |
| Height | : | 2-3/4 in |
| Length | : | 2-3/4 in |
| Load Capacity | : | 7000 lb Static |
| Outside Diameter | : | 2-1/4 in |
| Series | : | FB Series |
| Shaft Diameter | : | 1 in |
| Temperature Rating | : | 550 deg F |
| Type | : | Closed Twin |
| Width | : | 5.33 in |
- High performance in contaminated, wash-down or submerged environments
- Proprietary, self-lubricating, composite bearing liner TEP 950
- Low friction, ideally suited for linear and rotary motion
- Precision machined aluminum sleeve
- Excellent performance in high-vibration and mechanical shock applications
- Corrosion resistant
- For low-profile applications such as packaging equipment
- Choose precision inside diameter bearings for precision fit-up
- Not self-aligning
- Less seal
- Closed pillow blocks are for end supported shafting
- For class L carbon steel or stainless steel shafting
