SNR® 5204EEG15 NTN5204EEG15
SNR® 5204EEG15 Angular Contact Bearing, 20 mm Dia Bore, 47 mm Dia Outside, 2 Rows, 20.6 mm W, 25 deg, 19.1 kN Dynamic/12.5 kN Static Load
- Manufacturer: NTN
- Brand Name: SNR®
- Part Number: NTN5204EEG15
- MPN: 5204EEG15
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
SNR®, 5204EEG15, Bearing, Angular Contact, 20 mm Bore, 47 mm OD, 2 Rows, 20.6 mm Width, 25 deg Contact Angle, 19.1 kN Dynamic/12.5 kN Static Load, -20 to 120 deg C
| Bore Diameter | : | 20 mm |
| Contact Angle | : | 25 deg |
| Load Capacity | : | 19.1 kN Dynamic/12.5 kN Static |
| Number of Rows | : | 2 |
| Outside Diameter | : | 47 mm |
| Temperature Rating | : | -20 to 120 deg C |
| Type | : | Angular Contact |
| Width | : | 20.6 mm |
Specification Sheet
