SNR 23038BKW33C3 Spherical Roller Bearing features 190 mm bore, 290 mm OD, and 75 mm width and open design. Key specifications include Steel cage and 1900 rpm. Its spherical roller geometry accommodates misalignment while providing high radial load capacity and useful axial-load capability.
SNR®, 23038BKW33C3, Roller Bearing, 190 mm Bore, 290 mm OD, 75 mm Width, Open Closure, Steel Cage, 1900 rpm Maximum
| Bore Diameter | : | 190 mm |
| Cage Material | : | Steel |
| Closure Type | : | Open |
| Maximum Speed | : | 1900 rpm |
| Outside Diameter | : | 290 mm |
| Width | : | 75 mm |
- Product type: Spherical Roller Bearing
- Dimensions: 190 mm bore x 290 mm outside diameter x 75 mm width
- Design: Tapered bore; double row; open
- Construction: Steel cage
- Radial internal clearance: C3
- Relubrication: Oil groove and lubrication holes in outer ring
- Tapered bore ratio: 1:12
- Maximum speed: 1,900 rpm
