SNR® 22311EKF800 NTN22311EKF800

The outer ring of this type of bearing has a spherical raceway that allows angular movement of the rings. This means that the bearing can accept high degrees of misalignment. Its internal design enables it to withstand very high radial loads and axial loads. Variants with a tapered bore allow fitting using an adapter sleeve. This type of bearing is particularly suited to heavy mechanical applications where it is difficult to align the seats and radial loads are high. It is well suited to severe operating conditions, involving impact or vibration.

SNR® Spherical Roller Bearing, Series: ULTAGE® 223, 55 mm Bore Dia, 120 mm Outside Dia, 2 Rows, 43 mm W, Open Closure, 296 kN, Through Hardened Steel Bearing, Machined Brass Alloy Cage, 3100 rpm Grease/4000 rpm Oil Maximum, -40 to 200 deg C

• The high radial accelerations of vibrating applications place a particular stress on the cage
• Specific dimensional tolerances guaranteed stability
• Reduced internal radial clearance easy set-up
• Surface optimization
• Reduced power consumption
• Improved performance and reduced friction torque
• Increased operating speeds
• Reduced operating costs
• Shaker screen
• Bearing with solid cage for high-vibration applications, special C4 clearance
• 1:12 tapered bore
• CN radial clearance
• Machined cage
• 296 kN dynamic/274 kN static
• Tapered bore

• Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/SNR_22308EF800_Catalog.pdf
