The outer ring of this type of bearing has a spherical raceway that allows angular movement of the rings. This means that the bearing can accept high degrees of misalignment. Its internal design enables it to withstand very high radial loads and axial loads. Variants with a tapered bore allow fitting using an adapter sleeve. This type of bearing is particularly suited to heavy mechanical applications where it is difficult to align the seats and radial loads are high. It is well suited to severe operating conditions, involving impact or vibration.
SNR® Spherical Roller Bearing, Series: 213, 80 mm Bore Dia, 170 mm Outside Dia, 2 Rows, 39 mm W, Open Closure, 305 kN, Through Hardened Steel Bearing, Steel Cage, 4900 rpm Maximum, -40 to 120 deg C
| Bearing Material | : | Through Hardened Steel |
| Bore Diameter | : | 80 mm |
| Cage Material | : | Steel |
| Closure Type | : | Open |
| Load Capacity | : | 305 kN |
| Maximum Speed | : | 4900 rpm |
| Number of Rows | : | 2 |
| Outside Diameter | : | 170 mm |
| Series | : | 213 |
| Temperature Rating | : | -40 to 120 deg C |
| Width | : | 39 mm |
- Item Features 01=The high radial accelerations of vibrating applications place a particular stress on the cage
- Item Features 02=Specific dimensional tolerances guaranteed stability
- Item Features 03=Reduced internal radial clearance easy set-up
- Item Features 04=Surface optimization
- Item Features 05=Reduced power consumption
- Item Features 06=Improved performance and reduced friction torque
- Item Features 07=Increased operating speeds
- Item Features 08=Reduced operating costs
- Item Features 09=Optimized internal design, symmetrical rollers
- Item Features 10=1:12 tapered bore
- Item Features 11=C3 radial clearance greater than normal
- Item Features 12=Pressed cage
- Item Features 13=Tapered bore
