SENQCIA 100-2RB MAX100-2R-10

SENQCIA Inspire Series™ SBR® riveted roller chain is manufactured in Japan in accordance with the ASME/ANSI B29.1 American roller chain standard. These solid bushing/solid roller chains offer exceptional performance and long life in a wide variety of applications. Chain pins are produced from a special boron steel to improve strength. Solid cold forged bushings and a patented pin treatment extend chain wear life and greatly reduce break-in wear. Packaged chains are pre-lubricated with high quality wax-type grease and come with a necessary connecting link to join the ends. Offset links (used to shorten or lengthen a chain strand by 1 pitch) are also available and sold separately. This chain is packaged in a 10 ft box.

SENQCIA Inspire Series™ SBR® Roller Chain, Riveted Standard, 1-1/4 in Pitch, 3/8 in Pin Dia, 2.96 in Pin Length, 3/4 in Roller Dia, 3/4 in Roller Width, 1.154 in Plate Height, 0.157 in Plate Thickness, 96 Links, 2 Strands, 53000 lb Average Tensile, 10 ft Overall Length, Carbon Steel

• Higher rated working loads
• Improved wear and abrasion resistance
• New boron steel pins for most sizes that increase strength and improve ductility
• Proprietary stainless steel blast for link plates and rollers to protect against rust
• Unique triple zone hardness on chain pins
• Wide waist link plates
• Redesigned high strength connecting link with flat style closing plates
• Superior special blend pre-lubricant

• Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Senqcia_Maxco_06BHMCL_Catalog.pdf
