Sealmaster® 715093 MORSC31DRT
Sealmaster® 715093 SC Series 1-Piece Non-Expansion Standard Duty Straight Bore Cylindrical Cartridge Ball Bearing, 1.938 in Dia Bore, 4.563 in OD, 1.469 in W, 52100 Steel Bearing
- Manufacturer: Regal Rexnord
- Brand Name: Sealmaster®
- Part Number: MORSC31DRT
- Alt Part Number: SC-31 DRT
- MPN: 715093
- UPC: 662461328132
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Sealmaster® Cylindrical Cartridge Ball Bearing, 1-Piece Non-Expansion Standard Duty Straight Bore, Series: SC Series, 1.938 in Bore Dia, 4.563 in Outside Dia, 1.469 in W, 5216 lb Static/7889 lb Dynamic, 52100 Steel Bearing, Cast Iron Cage, 3550 rpm Maximum, 220 deg F, Black Oxide
| Bearing Material | : | 52100 Steel |
| Bore Diameter | : | 1.938 in |
| Cage Material | : | Cast Iron |
| Finish | : | Black Oxide |
| Load Capacity | : | 5216 lb Static/7889 lb Dynamic |
| Maximum Speed | : | 3550 rpm |
| Outside Diameter | : | 4.563 in |
| Series | : | SC Series |
| Temperature Rating | : | 220 deg F |
| Type | : | 1-Piece Non-Expansion Standard Duty Straight Bore |
| Width | : | 1.469 in |
- Item Features 01=Zone hardened inner ring with 120 deg spacing set screw locking with diamond faceted set screws
- Item Features 02=High temperature felt labyrinth seal and flinger for dry and dusty environment
- Item Features 03=Increased internal clearance and high temperature grease
- Item Features 04=Unique land riding retainer design provides superior pocket clearance that allows for 360 deg grease circulation around the rolling elements resulting in better retained and utilized lubrication
- Item Features 05=Sealmaster exclusive lock and pin dimple for direct lubrication and anti-rotation
