Sealmaster® 706069 MORMSF36TC
  1. pin-int

Sealmaster® 706069 MORMSF36TC

Sealmaster® 706069 MSF Non-Expansion Round Straight Standard-Duty Flange Mount Ball Bearing Unit, 2-1/4 in Dia Bore, 5-5/8 in L Bolt Center-to-Center, 4-Bolt Flange Mount, 6-7/8 in OAL/Dia

  • Manufacturer: Regal Rexnord
  • Brand Name: Sealmaster®
  • Part Number: MORMSF36TC
  • MPN: 706069
  • UPC: 662461035184
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

Sealmaster® gold mounted ball bearings feature a wide outer race insert bearing with land riding metallic retainer. The black oxide treated bearing steel insert features an exclusive lock pin and dimple system providing a direct path for lubrication into the bearing and prevents outer ring rotation within the housing. Shaft lock is achieved by either setscrew or Skwezloc® concentric locking collar. The felt seal with flinger provide a good balance between contaminant entry, GoldPlex® HP grease loss and friction.

Sealmaster® Flange Mount Ball Bearing Unit, Non-Expansion Round Straight Standard-Duty, Series: MSF, 2-1/4 in Bore, 5-5/8 in Bolt Center-to-Center Length, 4-Bolt Flange Mounting, 6-7/8 in Overall Length/Diameter, 2-3/4 in Overall Depth, 6-7/8 in Overall Height, Skwezloc® Locking Locking Device, Steel Bearing, Nitrile Rubber Seal, 11789 lb Dynamic/8150 lb Static Load, 2550 rpm Maximum, -20 to 250 deg F, Uncoated

Bearing Material      :      Steel
Bolt Center-to-Center Length      :      5-5/8 in
Bore Diameter      :      2-1/4 in
Finish      :      Uncoated
Flange Mounting Type      :      4-Bolt
Load Capacity      :      11789 lb Dynamic/8150 lb Static
Locking Device      :      Skwezloc® Locking
Maximum Speed      :      2550 rpm
Overall Depth      :      2-3/4 in
Overall Height      :      6-7/8 in
Overall Length/Diameter      :      6-7/8 in
Seal Material      :      Nitrile Rubber
Series      :      MSF
Temperature Rating      :      -20 to 250 deg F
Type      :      Non-Expansion Round Straight Standard-Duty
  • Wide outer ring
  • Lock pin and dimple system
  • Single lip contact seal consists of a nitrile rubber washer in metal shroud to shield the lip from large contaminants
  • Zone hardened inner race
  • Land riding retainer
  • GoldPlex-HP grease
  • 52100 black oxide coated steel bearing
  • Solid cast iron housing
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Sealmaster_MSF15_Specification_Sheet.pdf
