Sealmaster® 703153 MOR3-28C
Sealmaster® 703153 Medium Duty Non-Expansion Straight Bore Ball Bearing Insert, 2-1/2 in Dia Bore, 4.921 in OD, 2-3/4 in W, 13971 lb Dynamic/10063 lb Static Load
- Manufacturer: Regal Rexnord
- Brand Name: Sealmaster®
- Part Number: MOR3-28C
- MPN: 703153
- UPC: 662461020104
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
Sealmaster® gold mounted ball bearings feature a wide outer race insert bearing with land riding metallic retainer. The black oxide treated bearing steel insert features an exclusive lock pin and dimple system providing a direct path for lubrication into the bearing and prevents outer ring rotation within the housing. Shaft lock is achieved by either setscrew or Skwezloc® concentric locking collar. The felt seal with flinger provide a good balance between contaminant entry, GoldPlex® HP grease loss and friction.
Sealmaster® Ball Bearing Insert, Medium Duty Non-Expansion Straight Bore, 2-1/2 in Bore, 4.921 in OD, 2-3/4 in Width, Double Seal Closure, 13971 lb Dynamic/10063 lb Static Load, Steel Bearing, Nitrile Rubber Seal, Brass Cage, 2250 rpm Maximum, 250 deg F, Black Oxide Coated
| Bearing Material | : | Steel |
| Bore Diameter | : | 2-1/2 in |
| Cage Material | : | Brass |
| Closure Type | : | Double Seal |
| Finish | : | Black Oxide Coated |
| Load Capacity | : | 13971 lb Dynamic/10063 lb Static |
| Maximum Speed | : | 2250 rpm |
| Outside Diameter | : | 4.921 in |
| Seal Material | : | Nitrile Rubber |
| Temperature Rating | : | 250 deg F |
| Type | : | Medium Duty Non-Expansion Straight Bore |
| Width | : | 2-3/4 in |
- Setscrew locking
- Contact seal type
- Lithium complex NLGI #2 grease with an EP additive
- Zone hardened inner race
- Wide outer race
- Lock pin and dimple system
- Land riding retainer
- Metal nameplate riveted to the housing allows for easy identification even after years of operation
- Without seal flinger
