Sealmaster® 702076 MOR3-4D
Sealmaster® 702076 Medium Duty Non-Expansion Straight Bore Ball Bearing Insert With Seal Flinger, 4 in Dia Bore, 7.48 in OD, 5-3/8 in W, 29905 lb Dynamic/23553 lb Static Load
- Manufacturer: Regal Rexnord
- Brand Name: Sealmaster®
- Part Number: MOR3-4D
- Alt Part Number: 3-4D
- MPN: 702076
- UPC: 662461015292
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Sealmaster® gold mounted ball bearings feature a wide outer race insert bearing with land riding metallic retainer. The black oxide treated bearing steel insert features an exclusive lock pin and dimple system providing a direct path for lubrication into the bearing and prevents outer ring rotation within the housing. Shaft lock is achieved by either setscrew or Skwezloc® concentric locking collar. The felt seal with flinger provide a good balance between contaminant entry, GoldPlex® HP grease loss and friction.
Sealmaster® Ball Bearing Insert, Medium Duty Non-Expansion Straight Bore, 4 in Bore, 7.48 in OD, 5-3/8 in Width, Double Seal Closure, 29905 lb Dynamic/23553 lb Static Load, Steel Bearing, Felt Seal, Brass Cage, 2400 rpm Maximum, 250 deg F, Black Oxide Coated
| Bearing Material | : | Steel |
| Bore Diameter | : | 4 in |
| Cage Material | : | Brass |
| Closure Type | : | Double Seal |
| Finish | : | Black Oxide Coated |
| Load Capacity | : | 29905 lb Dynamic/23553 lb Static |
| Maximum Speed | : | 2400 rpm |
| Outside Diameter | : | 7.48 in |
| Seal Material | : | Felt |
| Temperature Rating | : | 250 deg F |
| Type | : | Medium Duty Non-Expansion Straight Bore |
| Width | : | 5-3/8 in |
- Double setscrew locking
- Lithium complex NLGI #2 grease with an EP additive
- Zone hardened inner race
- Wide outer race
- Lock pin and dimple system
- Land riding retainer
- Metal nameplate riveted to the housing allows for easy identification even after years of operation
