Sealmaster® 1430709000 MORTF7YN

Sealmaster® two and three piece rod end bearing housing designs have been optimized for overall strength. This housing advantage and variety of outer race materials including brass, steel, Delrin® and PTFE liners provide a wide selection of application solutions. Sealmaster® rod end bearings can be joined together or connected with a threaded rod or tube as linkage assemblies for flexibility in motion transfer. In addition Sealmaster® rod end bearings can accommodate angular misalignment to provide ease in assembly and smooth motion transfer in a variety of applications.

Sealmaster® Bearing Rod End, 3-Piece Commercial Grade General Purpose, Series: TF-N, 7/16 in Bore, 1-1/8 in OD, 5/8 in Width, Female UNF Thread, 7/16-20 Dia x 1.031 in L Thread, 1.812 in Center Line Length, 5350 lb Static Load, 350 deg F, Carbon Steel

• Item Features 01=Machined carbon steel housings with protective coating for corrosion resistance
• Item Features 02=Alloy steel heat treated and chrome plated ball for wear resistance properties
• Item Features 03=Wrench flat on female rod ends facilitates assembly
• Item Features 04=Designed with 1-piece bronze race for lower coefficient of friction
• Item Features 05=Right hand internal thread
• Item Features 06=Carbon steel corrosion resistant plating Y-stud

• Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Sealmaster_1410308000_Catalog.pdf
