Rex® 10427942 REXZB2308
  1. pin-int

Rex® 10427942 REXZB2308

Rex® 10427942 2000 Fixed Normal Duty Flanged Block Spherical Roller Bearing, 3-1/2 in Dia Bore, 6-23/32 in L Bolt Center-to-Center, 4-3/4 in Dia Bolt Circle, 4-Bolt Square Flange Mount, 8-7/16 in OAL/Dia

  • Manufacturer: Regal Rexnord
  • Brand Name: Rex®
  • Part Number: REXZB2308
  • Alt Part Number: ZB2308
  • MPN: 10427942
  • UPC: 698210173906
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Rex® Bearings represent the continuation of 80 years of bearing technology and experience. This design allows the inner race to misalign freely in any direction up to 4 deg of total misalignment. By design, Rex® Bearings accept both radial and thrust loads under static, oscillatory or dynamic conditions. The load is taken on the roller raceways, not the roller ends. This means that when thrust is loaded up to their allowable limit, Rex® Bearings do not exhibit roller end wear.

Rex® Flanged Block Spherical Roller Bearing, Fixed Normal Duty, Series: 2000, 3-1/2 in Bore, 6-23/32 in Bolt Center-to-Center Length, 4-3/4 in Diameter Bolt Circle, 4-Bolt Square Flange Mounting, 8-7/16 in Overall Length/Diameter, 4-3/8 in Overall Depth, 8-7/16 in Overall Height, Single Set Screw Collar Locking Device, Cast Iron Bearing, Metal Seal, 84330 lb Dynamic/90700 lb Static Load, 2400 rpm Maximum, 225 deg F, Powder Coated

Bearing Material      :      Cast Iron
Bolt Center-to-Center Length      :      6-23/32 in
Bolt Circle Diameter      :      4-3/4 in
Bore Diameter      :      3-1/2 in
Finish      :      Powder Coated
Flange Mounting Type      :      4-Bolt Square
Load Capacity      :      84330 lb Dynamic/90700 lb Static
Locking Device      :      Single Set Screw Collar
Maximum Speed      :      2400 rpm
Overall Depth      :      4-3/8 in
Overall Height      :      8-7/16 in
Overall Length/Diameter      :      8-7/16 in
Seal Material      :      Metal
Series      :      2000
Temperature Rating      :      225 deg F
Type      :      Fixed Normal Duty
  • Easy bearing clearance adjustment
  • Pre-lubricated with standard grease for normal operation
  • Super-finished raceways provide a cool running and quiet, high-speed and high-load capacity bearing
  • Shaft ready and rugged housing
  • Type Z clearance seal
  • Factory set clearance and lubrication
  • Simplest installation
  • Most economical
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Rex_AKBR5215_Catalog.pdf
