RBC® KP37BSFS464 RBCKP37BSFS464
  1. pin-int

RBC® KP37BSFS464 RBCKP37BSFS464

RBC® KP37BSFS464 KP-BS Torque Tube Standard Externally Self-Aligning Airframe Bearing, Ball Bearing, 2.313 in Dia Bore, 3-1/4 in OD, 0.437 in W, 15800 lb Load

  • Manufacturer: RBC Bearings Incorporated
  • Brand Name: RBC®
  • Part Number: RBCKP37BSFS464
  • MPN: KP37BSFS464
  • UPC: 637400552046
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at EVANSVILLE, IN
  • loading Check Availability at All Branches

RBC® Self-Aligning Airframe Bearing, Torque Tube Standard Externally, Series: KP-BS, Ball Bearing, 2.313 in Bore Dia, 1 Row, 3-1/4 in Outside Dia, 0.437 in W, 15800 lb, 52100 Steel Bearing, PTFE Seal, -65 to 350 deg F, Cadmium

Bearing Material      :      52100 Steel
Bearing Type      :      Ball
Bore Diameter      :      2.313 in
Finish      :      Cadmium
Load Capacity      :      15800 lb
Number of Rows      :      1
Outside Diameter      :      3-1/4 in
Seal Material      :      PTFE
Series      :      KP-BS
Temperature Rating      :      -65 to 350 deg F
Type      :      Torque Tube Standard Externally
Width      :      0.437 in
  • Single row extra light duty airframe control ball bearing
  • External self-aligning design to compensate for initial misalignment
  • CRES seal caps
  • Exposed surfaces except bore, caps and seals are cadmium plated
  • Prelubricated for life
  • This bearing is not intended for use in any aerospace application
  • Contact seals
  • Mobil 28® grease
  • 15800 lb dynamic/15800 lb static
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RBC_10NBC1620YZP_Catalog.pdf
