Power Team® RLS500S SPXRLS500S
Power Team® RLS500S Heavy Duty Low Profile Welded Hydraulic Cylinder, 50 ton, 3-1/2 in Bore, 5/8 in L Stroke, 2-5/8 in H Retract, 1-3/4 in Dia Rod, 10394 psi
- Manufacturer: Hydraulic Technologies
- Brand Name: Power Team®
- Part Number: SPXRLS500S
- MPN: RLS500S
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Power Team® Hydraulic Cylinder, Heavy Duty Low Profile Welded, Series: RLS, 50 ton Capacity, 3-1/2 in Bore, 5/8 in Stroke Length, 2-5/8 in H Retract, 27/32 in Port, 1-3/4 in Rod Diameter, 10394 psi Pressure, 4-1/2 x 5-1/2 in OD
| Bore Size | : | 3-1/2 in |
| Capacity | : | 50 ton |
| Dimensions | : | 4-1/2 x 5-1/2 in OD |
| Port Size | : | 27/32 in |
| Pressure Rating | : | 10394 psi |
| Retract | : | 2-5/8 in H |
| Rod Diameter | : | 1-3/4 in |
| Series | : | RLS |
| Stroke Length | : | 5/8 in |
| Type | : | Heavy Duty Low Profile Welded |
- Cylinder body, piston and gland nut power tech treated for corrosion and abrasion-resistance
- Standard domed piston rod (5 to 30 ton) or swivel cap (50 to 150 ton) minimize effects of off-center loading
- Unique heavy duty spring provides fast piston return
- A 9796 3/8 in NPTF female half coupler is standard with each cylinder
- Oil ports are 3/8 in NPTF
- Couplers on all cylinders are angled upward for extra clearance
