Power Team® RH302 SPXRH302
Power Team® RH302 RH Series Center Hole Welded Hydraulic Cylinder, 30 ton, 2-1/2 in L Stroke, 6-1/4 in H Retract, 3-1/4 in Dia Rod, 9457 psi
- Manufacturer: SPX FLOW
- Brand Name: Power Team®
- Part Number: SPXRH302
- MPN: RH302
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Power Team® Hydraulic Cylinder, Center Hole Welded, Series: RH Series, 30 ton Capacity, 2-1/2 in Stroke Length, 6-1/4 in H Retract, 1-5/32 in Port, 3-1/4 in Rod Diameter, 9457 psi Pressure, 4-3/4 in OD
| Capacity | : | 30 ton |
| Dimensions | : | 4-3/4 in OD |
| Port Size | : | 1-5/32 in |
| Pressure Rating | : | 9457 psi |
| Retract | : | 6-1/4 in H |
| Rod Diameter | : | 3-1/4 in |
| Series | : | RH Series |
| Stroke Length | : | 2-1/2 in |
| Type | : | Center Hole Welded |
- Item Features 01=Interchangeable piston head inserts provide versatility of application
- Item Features 02=Single acting models feature threaded collar
- Item Features 03=Withstands full dead end load
- Item Features 04=Corrosion-resistant standpipe has power tech treatment
- Item Features 05=All cylinders except RH120 are furnished with a 9796 3/8 in NPT female half coupler
- Item Features 06=Aluminum cylinder body and piston are featured on the RHA306 cylinder
Instruction/Installation Manual
