Power Team® RH120 SPXRH120
  1. pin-int

Power Team® RH120 SPXRH120

Power Team® RH120 RH Series Center Hole Spring-Return Single-Acting Hydraulic Cylinder, 12 ton Load, 2-3/16 in H Min, 2-1/2 in H Max, 5/16 in

  • Manufacturer: Hydraulic Technologies
  • Brand Name: Power Team®
  • Part Number: SPXRH120
  • MPN: RH120
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Power Team® Hydraulic Cylinder, Center Hole Spring-Return Single-Acting, Series: RH Series, 12 ton Load, 2-3/16 in Minimum Height, 2-1/2 in Maximum Height, 5/16 in Piston Stroke, 2-3/4 in Base Width

Base Width      :      2-3/4 in
Load Capacity      :      12 ton
Maximum Height      :      2-1/2 in
Minimum Height      :      2-3/16 in
Piston Stroke      :      5/16 in
Series      :      RH Series
Type      :      Center Hole Spring-Return Single-Acting
  • Cylinder body, piston and gland nut Power-tech treated for corrosion and abrasion resistance
  • Most models feature threaded collar, excludes the RH203 and RHA306 models
  • All cylinders are furnished with a 9796 3/8 NPT female half coupler, except the rh120
  • Aluminum cylinder body and piston are featured on the RHA306 cylinder
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Power_Team_C1010CBT_Manual.pdf
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Power_Team_RH1003_Catalog.pdf
  • pdfLine Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Power_Team_RH120_Line_Drawing.pdf
