Power Team® hand pumps, with the angled fill port, have a built in "relief valve" protection system. This system is designed to protect over pressurization of the reservoir from sudden back pressure. This system also works as a seal to prevent oil leaks.
Power Team® Hand Pump, 2-Speed Single Acting, 1.5 gal Tank, 310 cu-in Pump, 325 to 10000 psi Pressure, 3/8 in NPTF Port, 22-5/8 in Overall Length, 8-1/2 in Overall Width, 6-7/8 in Overall Height
| Overall Height | : | 6-7/8 in |
| Overall Length | : | 22-5/8 in |
| Overall Width | : | 8-1/2 in |
| Port Size | : | 3/8 in NPTF |
| Pressure Rating | : | 325 to 10000 psi |
| Pump Capacity | : | 310 cu-in |
| Tank Capacity | : | 1.5 gal |
| Type | : | 2-Speed Single Acting |
- Rugged all metal construction for strength and durability that won't burn through in welding environments
- Heavy duty, formed metal handle provides less flex and less operator fatigue than round or composite handles
- Convenient fill port on P23 and P55 allows pumps to be filled in a horizontal or vertical position
- Fill cap seal acts as safety valve to prevent over-pressurizing of reservoir
- Relief valve inboard of check valve prevents loads from drifting down
- Large valve knob gives added control for slowly metering loads down
