Pneuforce® PC10-U01 PNEPC10-U01
  1. pin-int

Pneuforce® PC10-U01 PNEPC10-U01

Pneuforce® PC10-U01 Fitting Male Straight Stud, 10 mm x 1/2 Nominal, Universal End Style, 14.7 to 150 psi Pressure, Plastic

  • Manufacturer: Vacuforce LLC.
  • Brand Name: Pneuforce®
  • Part Number: PNEPC10-U01
  • MPN: PC10-U01
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

Pneuforce®, PC10-U01, Male Straight Stud, Fitting, 10 mm x 1/2 Nominal, Universal End Style, 17 mm Hex, 26.3 mm Length, 14.7 to 150 psi Pressure, 32 to 140 deg F, Plastic

End Style      :      Universal
Hex Size      :      17 mm
Length      :      26.3 mm
Material      :      Plastic
Nominal Size      :      10 mm x 1/2
Pressure Rating      :      14.7 to 150 psi
Temperature Rating      :      32 to 140 deg F
Type      :      Fitting
  • Threaded Body - Nickel Plated Brass
  • Release Collar - POM (Polyoxymethylene)
  • Gripping Claw - Stainless Steel
  • O Ring Seals - NBR (Nitrile Rubber)
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Vacuforce_JSC10_G04_Specification_Sheet.pdf
