NTN WC87503 BCAWC87503
NTN WC87503 WC87000 Round Bore Standard Small Deep Groove Radial Ball Bearing, 17 mm Dia Bore, 40 mm OD, 1 Rows, 14.288 mm W, 9600 N Load
- Manufacturer: NTN
- Brand Name: NTN
- Part Number: BCAWC87503
- MPN: WC87503
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
Deep groove ball bearings are very widely used. A deep groove is formed on each inner and outer ring of the bearing enabling them to sustain radial and axial loads in either direction as well as well as the complex loads which result from the combination of these forces. Deep groove ball bearings are suitable for high speed applications.
NTN Deep Groove Radial Ball Bearing, Round Bore Standard Small, Series: WC87000, 17 mm Bore, 40 mm OD, 1 Rows, 14.288 mm Width, Single Shielded/Sealed Closure, 9600 N Load, High Carbon Chrome Steel Bearing, Nitrile Rubber Seal, Pressed Steel Cage, 12000 rpm Grease Maximum, -40 to 120 deg C
| Bearing Material | : | High Carbon Chrome Steel |
| Bore Diameter | : | 17 mm |
| Cage Material | : | Pressed Steel |
| Closure Type | : | Single Shielded/Sealed |
| Load Capacity | : | 9600 N |
| Maximum Speed | : | 12000 rpm Grease |
| Number of Rows | : | 1 |
| Outside Diameter | : | 40 mm |
| Seal Material | : | Nitrile Rubber |
| Series | : | WC87000 |
| Temperature Rating | : | -40 to 120 deg C |
| Type | : | Round Bore Standard Small |
| Width | : | 14.288 mm |
- ISO class 0 precision rating
- Single shielded and single sealed contact nitrile rubber seal
- CN radial clearance
- 9600 N dynamic/4600 N static
