NTN UCUP205-100D1 NTNUCUP205-100D1
NTN UCUP205-100D1 Light Duty Narrow Style Pillow Block Ball Bearing Unit, 25.4 mm Dia Bore, 56 mm L Bolt Center-to-Center, 36.5 mm Base to Bore Centerline, 84 mm OAL x 72 mm OAH
- Manufacturer: NTN
- Brand Name: NTN
- Part Number: NTNUCUP205-100D1
- MPN: UCUP205-100D1
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
NTN Pillow Block Ball Bearing Unit, Light Duty Narrow Style, Series: UCUP2, 25.4 mm Bore, 56 mm Bolt Center-to-Center Length, 36.5 mm Base to Bore Centerline, 84 mm Overall Length, 38.8 mm Overall Width, 72 mm Overall Height, Two-Bolt Base Mounting, Round Bore, 38 mm Base Width, Set Screw Locking Device, Contact Seal, 14000 N Dynamic/7850 N Static Load, -40 to 120 deg C, 5900 rpm Maximum, Steel
| Base Width | : | 38 mm |
| Base to Bore Centerline | : | 36.5 mm |
| Bolt Center-to-Center Length | : | 56 mm |
| Bore Diameter | : | 25.4 mm |
| Bore Type | : | Round |
| Load Capacity | : | 14000 N Dynamic/7850 N Static |
| Locking Device | : | Set Screw |
| Material | : | Steel |
| Maximum Speed | : | 5900 rpm |
| Mounting Type | : | Two-Bolt Base |
| Overall Height | : | 72 mm |
| Overall Length | : | 84 mm |
| Overall Width | : | 38.8 mm |
| Seal Type | : | Contact |
| Series | : | UCUP2 |
| Temperature Rating | : | -40 to 120 deg C |
| Type | : | Light Duty Narrow Style |
- Relubricatable
- Nitrile rubber seal
- Open end
