NTN UCT322D1 NTNUCT322D1
NTN UCT322D1 Heavy Duty Take-Up Ball Bearing Unit With Flinger, 110 mm Dia Bore, 385 mm L x 117 mm W x 320 mm H, 205000 N Load
- Manufacturer: NTN
- Brand Name: NTN
- Part Number: NTNUCT322D1
- MPN: UCT322D1
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
NTN Take-Up Ball Bearing Unit, Heavy Duty, Series: UCT, 110 mm Bore Dia, 385 mm Length, 117 mm Width, 320 mm Height, 205000 N, -40 to 120 deg C, Gray
| Bore Diameter | : | 110 mm |
| Color | : | Gray |
| Height | : | 320 mm |
| Length | : | 385 mm |
| Load Capacity | : | 205000 N |
| Series | : | UCT |
| Temperature Rating | : | -40 to 120 deg C |
| Type | : | Heavy Duty |
| Width | : | 117 mm |
- Contact nitrile rubber seal
- UC322D1 ball bearing
- T322D1 cast iron housing
- Setscrew locking device
- Relubricatable
- Wide inner ring
- 1300 rpm rotational speed
- 205000 N dynamic/179000 N static
