NTN NUP2215EG1C3 NTNNUP2215EG1C3

Cylindrical Roller Bearing have rollers which are essentially cylindrical in shape. This provides a modified line contact with the cylindrical inner and outer ring raceways, while the rollers are guided by ground ribs on either the inner or outer ring. The cylindrical shape allows the inner ring to have axial movement relative to the outer ring (except the NH type). This is especially important when accommodating thermal expansion when both rings must be press fitted. In this series, the NJ, NF and NH types can carry light or intermittent thrust loads. The NN3000 and NN3000K series are available in high precision tolerances and are well suited for use in machine tool spindles.

NTN Cylindrical Roller Bearing, Series: NU22, 75 mm Bore Dia, 130 mm Outside Dia, 1 Row, 31 mm W, Open Closure, 207000 N, Pressed Steel Cage, 4200 rpm Grease/4900 rpm Oil Maximum, -40 to 120 deg C

• Item Features 01=Unable to accommodate even the lightest axial loads
• Item Features 02=This type is extremely suitable for and widely used as the floating side bearing
• Item Features 03=High capacity cylindrical roller bearings
• Item Features 04=ISO class 0 tolerance rating
• Item Features 05=C3 radial clearance greater than normal
• Item Features 06=Round bore
• Item Features 07=162000 N dynamic/207000 N static
• Item Features 08=Without oil hole

• Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/NTN_3201_Catalog.pdf
