NTN NJ309EAG1C3

NTN NJ309EAG1C3 NJ3 Cylindrical Roller Bearing, 45 mm Dia Bore, 100 mm Dia Outside, 1 Rows, 25 mm W

  • Manufacturer: NTN
  • Brand Name: NTN
  • Part Number: NTNNJ309EAG1C3
  • MPN: NJ309EAG1C3
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

NTN NJ309EAG1C3 NJ3 Cylindrical Roller Bearing features 45 mm bore, 100 mm OD, and 25 mm width and single-row design. Key specifications include Brass cage. Cylindrical rollers provide high radial load capacity and rigidity for demanding rotating equipment.

NTN, NJ309EAG1C3, Cylindrical Roller Bearing, Series: NJ3, 45 mm Bore, 100 mm OD, 1 Rows, 25 mm Width, Brass Cage

Bore Diameter      :      45 mm
Cage Material      :      Brass
Number of Rows      :      1
Outside Diameter      :      100 mm
Series      :      NJ3
Width      :      25 mm
  • Product type: Cylindrical Roller Bearing
  • Dimensions: 45 mm bore x 100 mm outside diameter x 25 mm width
  • Design: Single row; separable; one-rib inner ring and two-rib outer ring; open
  • Internal design: EA high-capacity / ULTAGE design
  • Construction: Machined-brass cage
  • Load direction: Radial load plus limited axial load in one direction
  • Radial internal clearance: C3
