NTN ASRPP205 NTNASRPP205
NTN ASRPP205 1-Piece Light Duty Pillow Block Ball Bearing Unit, 25 mm Dia Bore, 95 mm L Bolt Center-to-Center, 33.3 mm Base to Bore Centerline, 117 mm OAL x 66.3 mm OAH
- Manufacturer: NTN
- Brand Name: NTN
- Part Number: NTNASRPP205
- MPN: ASRPP205
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
-
Price:
NTN Pillow Block Ball Bearing Unit, 1-Piece Light Duty, Series: ASRPP2, 25 mm Bore, 95 mm Bolt Center-to-Center Length, 33.3 mm Base to Bore Centerline, 117 mm Overall Length, 38.5 mm Overall Width, 66.3 mm Overall Height, 38 mm Base Width, Set Screw Locking Device, Contact Seal, 14000 N Dynamic/7850 N Static Load, -40 to 120 deg C, 5900 rpm Maximum, Pressed Steel
| Base Width | : | 38 mm |
| Base to Bore Centerline | : | 33.3 mm |
| Bolt Center-to-Center Length | : | 95 mm |
| Bore Diameter | : | 25 mm |
| Load Capacity | : | 14000 N Dynamic/7850 N Static |
| Locking Device | : | Set Screw |
| Material | : | Pressed Steel |
| Maximum Speed | : | 5900 rpm |
| Overall Height | : | 66.3 mm |
| Overall Length | : | 117 mm |
| Overall Width | : | 38.5 mm |
| Seal Type | : | Contact |
| Series | : | ASRPP2 |
| Temperature Rating | : | -40 to 120 deg C |
| Type | : | 1-Piece Light Duty |
- Non-relubricatable
- Nitrile rubber seal
- Open end
