NTN 6205LLBC3/EM NTN6205LL
NTN 6205LLBC3/EM 62 Series Round Bore Standard Small Deep Groove Radial Ball Bearing, 25 mm Dia Bore, 52 mm OD, 1 Rows, 15 mm W, 14000 N Load
- Manufacturer: NTN
- Brand Name: NTN
- Part Number: NTN6205LL
- MPN: 6205LLBC3/EM
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
NTN 6205LLBC3/EM 62 Series Round Bore Standard Small Deep Groove Radial Ball Bearing features 25 mm bore, 52 mm OD, and 15 mm width and single-row and double-sealed design. Key specifications include High Carbon Chrome Steel bearing, Pressed Steel cage, and Nitrile Rubber seals, 14000 N dynamic and 7850 N static load ratings, and 13000 rpm Grease; temperature -40 to 120 deg C. The deep-groove design supports radial loads plus axial loads in either direction while remaining suitable for high-speed operation.
NTN Deep Groove Radial Ball Bearing, Round Bore Standard Small, Series: 62 Series, 25 mm Bore, 52 mm OD, 1 Rows, 15 mm Width, Double Seal Closure, 14000 N Load, High Carbon Chrome Steel Bearing, Nitrile Rubber Seal, Pressed Steel Cage, 13000 rpm Grease Maximum, -40 to 120 deg C
| Bearing Material | : | High Carbon Chrome Steel |
| Bore Diameter | : | 25 mm |
| Cage Material | : | Pressed Steel |
| Closure Type | : | Double Seal |
| Load Capacity | : | 14000 N |
| Maximum Speed | : | 13000 rpm Grease |
| Number of Rows | : | 1 |
| Outside Diameter | : | 52 mm |
| Seal Material | : | Nitrile Rubber |
| Series | : | 62 Series |
| Temperature Rating | : | -40 to 120 deg C |
| Type | : | Round Bore Standard Small |
| Width | : | 15 mm |
- Product type: Deep Groove Ball Bearing
- Dimensions: 25 mm bore x 52 mm outside diameter x 15 mm width
- Design: Single row; double seal
- Sealing: Non-contact seals on both sides
- Construction: High-carbon chrome steel bearing; Pressed-steel cage; Nitrile-rubber seals
- Load ratings: 14,000 N dynamic / 7,850 N static
- Operating limits: 13,000 rpm (grease); -40 to 120 °C
- Radial internal clearance: C3
- Precision class: ISO 0
