Tapered roller bearings utilize conical rollers and raceways, arranged so that the rollers and raceways meet at a common apex. The rollers are guided by contact between the large end of the roller and a rib on the inner ring. This provides high capacity for radial and single thrust loads.
NTN Tapered Roller Bearing, Round Bore, 55 mm Bore Dia, 100 mm Outside Dia, 22.75 mm W, Open Closure, 111000 N, Case Carburized Steel Bearing, 3600 rpm Grease/4900 rpm Oil Maximum, -40 to 120 deg C
| Bearing Material | : | Case Carburized Steel |
| Bore Diameter | : | 55 mm |
| Closure Type | : | Open |
| Load Capacity | : | 111000 N |
| Maximum Speed | : | 3600 rpm Grease/4900 rpm Oil |
| Outside Diameter | : | 100 mm |
| Temperature Rating | : | -40 to 120 deg C |
| Type | : | Round Bore |
| Width | : | 22.75 mm |
- Class 0 precision rating
- Without oil hole
- 93000 N dynamic/111000 N static
