NTN 29252 NTN29252
NTN 29252 Round Bore Self-Aligning Spherical Roller Thrust Bearing, 260 mm Dia Bore, 360 mm OD, 1 Row, 60 mm W, 3950000 N Load
- Manufacturer: NTN
- Brand Name: NTN
- Part Number: NTN29252
- MPN: 29252
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
NTN 29252 Round Bore Self-Aligning Spherical Roller Thrust Bearing features 260 mm bore, 360 mm OD, and 60 mm width, single-row design, and 292 series. Key specifications include Through Hardened Steel bearing, 870000 N dynamic and 3950000 N static load ratings, and 1100 rpm; temperature -40 to 120 deg C. Its spherical roller thrust geometry accommodates misalignment while carrying high axial loads with a concurrent radial load component.
NTN Spherical Roller Thrust Bearing, Round Bore Self-Aligning, Series: 292, 260 mm Bore Dia, 360 mm Outside Dia, 1 Rows, 60 mm Width, 3950000 N, Through Hardened Steel Bearing, 1100 rpm Maximum, -40 to 120 deg C
| Bearing Material | : | Through Hardened Steel |
| Bore Diameter | : | 260 mm |
| Load Capacity | : | 3950000 N |
| Maximum Speed | : | 1100 rpm |
| Number of Rows | : | 1 |
| Outside Diameter | : | 360 mm |
| Series | : | 292 |
| Temperature Rating | : | -40 to 120 deg C |
| Type | : | Round Bore Self-Aligning |
| Width | : | 60 mm |
- Product type: Spherical Roller Thrust Bearing
- Series: 292
- Dimensions: 260 mm bore x 360 mm outside diameter x 60 mm width
- Design: Single row
- Construction: Through-hardened steel bearing
- Load ratings: 870,000 N dynamic / 3,950,000 N static
- Operating limits: 1,100 rpm; -40 to 120 °C
