NTN 21309CW33C3 NTN21309CW33C3
NTN 21309CW33C3 Spherical Roller Bearing With Oil Groove, 45 mm Dia Bore, 100 mm OD, 2 Rows, 25 mm W, 106000 N Load
- Manufacturer: NTN
- Brand Name: NTN
- Part Number: NTN21309CW33C3
- MPN: 21309CW33C3
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
NTN 21309CW33C3 Spherical Roller Bearing With Oil Groove features 45 mm bore, 100 mm OD, and 25 mm width, Tapered bore, double-row, and open design, and 213 series. Key specifications include Through Hardened Steel bearing and Steel cage, 102000 N dynamic and 106000 N static load ratings, and 4400 rpm Grease/5700 rpm Oil; temperature -40 to 120 deg C. Its spherical roller geometry accommodates misalignment while providing high radial load capacity and useful axial-load capability.
NTN Spherical Roller Bearing, Series: 213, 45 mm Bore Dia, 100 mm Outside Dia, 2 Rows, 25 mm W, Open Closure, 106000 N, Through Hardened Steel Bearing, Steel Cage, 4400 rpm Grease/5700 rpm Oil Maximum, -40 to 120 deg C
| Bearing Material | : | Through Hardened Steel |
| Bore Diameter | : | 45 mm |
| Cage Material | : | Steel |
| Closure Type | : | Open |
| Load Capacity | : | 106000 N |
| Maximum Speed | : | 4400 rpm Grease/5700 rpm Oil |
| Number of Rows | : | 2 |
| Outside Diameter | : | 100 mm |
| Series | : | 213 |
| Temperature Rating | : | -40 to 120 deg C |
| Width | : | 25 mm |
- Product type: Spherical Roller Bearing
- Series: 213
- Dimensions: 45 mm bore x 100 mm outside diameter x 25 mm width
- Design: Cylindrical bore; double row; open
- Construction: Through-hardened steel bearing; Steel cage
- Load ratings: 102,000 N dynamic / 106,000 N static
- Operating limits: 4,400 rpm (grease) / 5,700 rpm (oil); -40 to 120 °C
- Radial internal clearance: C3
- Relubrication: Oil groove and lubrication holes in outer ring
