NTN 16012C3 NTN16012C3
NTN 16012C3 Straight Bore Ball Bearing, 60 mm Dia Bore, 95 mm Dia Outside, 1 Rows, 11 mm W, 4960 lbf Dynamic/3930 lbf Static Load
- Manufacturer: NTN
- Brand Name: NTN
- Part Number: NTN16012C3
- MPN: 16012C3
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/PK
-
Price:
NTN, 16012C3, Ball Bearing, Straight Bore, 60 mm Bore, 95 mm OD, 1 Rows, 11 mm Width, Open Closure, 4960 lbf Dynamic/3930 lbf Static Load, High Carbon Chrome Steel Bearing, 8300 rpm Maximum, -40 to 250 deg F
| Bearing Material | : | High Carbon Chrome Steel |
| Bore Diameter | : | 60 mm |
| Cage Material | : | Pressed Steel |
| Closure Type | : | Open |
| Load Capacity | : | 4960 lbf Dynamic/3930 lbf Static |
| Maximum Speed | : | 8300 rpm |
| Number of Rows | : | 1 |
| Outside Diameter | : | 95 mm |
| Temperature Rating | : | -40 to 250 deg F |
| Type | : | Straight Bore |
| Width | : | 11 mm |
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/NTN_16012C3_Specification_Sheet.pdf
