NSK 6326MC3 NSK6326MC3
NSK 6326MC3 Medium Deep Groove Ball Bearing, 130 mm Dia Bore, 280 mm OD, 1 Row, 58 mm W, 229000 N Dynamic/214000 N Static Load
- Manufacturer: NSK AMERICAS
- Brand Name: NSK
- Part Number: NSK6326MC3
- MPN: 6326MC3
- UPC: 029176521683
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
Deep Groove Ball Bearings (DGBB) are the most common form of rolling bearings and are used in a variety of applications, particularly those where high speeds and low power loss are required. NSK DGBB can handle not only radial forces, but also moderate axial loads in both directions. They are easy to install and can be deployed in a variety of configurations.
NSK Deep Groove Ball Bearing, Medium, Series: 6300, 130 mm Bore Dia, 280 mm Outside Dia, 1 Row, 58 mm Width, Open Closure, 229000 N Dynamic/214000 N Static, Brass Cage, 2200 rpm Grease/2600 rpm Oil Maximum
| Bore Diameter | : | 130 mm |
| Cage Material | : | Brass |
| Closure Type | : | Open |
| Load Capacity | : | 229000 N Dynamic/214000 N Static |
| Maximum Speed | : | 2200 rpm Grease/2600 rpm Oil |
| Number of Rows | : | 1 |
| Outside Diameter | : | 280 mm |
| Series | : | 6300 |
| Type | : | Medium |
| Width | : | 58 mm |
- High quality steel - ultra clean steel made to extend bearing life by up to 80%
- Advanced grease technology - NSK lubricants made to extend grease life and improve bearing performance
- Super finished raceways - specially honed to minimize noise and improve the grease distribution
- Patented seals - provide a barrier to contamination in tough environments
