NSK 22217CAME4C3 NSK22217CAME4C3
NSK 22217CAME4C3 HPS™ Medium Spherical Roller Bearing, 85 mm Dia Bore, 150 mm OD, 2 Rows, 36 mm W, 310000 N Dynamic/325000 N Static Load
- Manufacturer: NSK AMERICAS
- Brand Name: NSK
- Part Number: NSK22217CAME4C3
- MPN: 22217CAME4C3
- UPC: 029176089800
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
NSKHPS™ Spherical Roller Bearings are state-of-the-art material technology bearings, suitable for high speeds and high loads. The enable equipment downsizing and are suitable for a wide variety of applications. HPS™ sphericals are available with both steel or brass cage.
NSK Spherical Roller Bearing, Medium, Series: HPS™ 222, 85 mm Bore Dia, 150 mm Outside Dia, 2 Rows, 36 mm Width, Open Closure, 310000 N Dynamic/325000 N Static, Steel Bearing, Brass Cage, 3400 rpm Grease/4300 rpm Oil Maximum, 200 deg C
| Bearing Material | : | Steel |
| Bore Diameter | : | 85 mm |
| Cage Material | : | Brass |
| Closure Type | : | Open |
| Load Capacity | : | 310000 N Dynamic/325000 N Static |
| Maximum Speed | : | 3400 rpm Grease/4300 rpm Oil |
| Number of Rows | : | 2 |
| Outside Diameter | : | 150 mm |
| Series | : | HPS™ 222 |
| Temperature Rating | : | 200 deg C |
| Type | : | Medium |
| Width | : | 36 mm |
- Highest load rating SRB's
- Optimal raceway design and surface finishing
- High cleanliness Z-steel
- Up to twice the operating life
- Up to 20% higher limiting speed
- 25% higher dynamic load rating
- Improved productivity lowers maintenance cost
- High load rating enables downsizing
- High temperature and misalignment
