Nice® 7520DLGTNTG18 RBC7520DLGTN

Nice® 7520DLGTNTG18 7500® Heavy Duty Non-Fill Slot Precision Deep Groove Ball Bearing, 1-1/4 in Dia Bore, 2-9/16 in OD, 1 Rows, 3/4 in W, 2620 lb Load

  • Manufacturer: RBC Bearings Incorporated
  • Brand Name: Nice®
  • Part Number: RBC7520DLGTN
  • MPN: 7520DLGTNTG18
  • UPC: 637400292782
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Pricing and Availability

The 7500® Series bearings are single row retainer type radial bearings, similar in construction to the 1600® Series bearings. They incorporate a highly effective single lip contact seal, with metal guard. The inner and outer rings are turned from chrome steel and after careful heat treatment the through hardened rings are accurately ground to close tolerances. The 7500® Series bearings are recommended for applications requiring the accuracy of rotation and quiet performance of close tolerance precision grade bearings, and where a superior seal is required to retain lubricant and keep the bearing free from dust and dirt.

Nice® Precision Deep Groove Ball Bearing, Heavy Duty Non-Fill Slot, Series: 7500®, 1-1/4 in Bore, 2-9/16 in OD, 1 Rows, 3/4 in Width, Double Seal Closure, 2620 lb Load, 52100 Steel Bearing, Nylon Cage, 5000 rpm Maximum, 300 deg F, Chrome Steel

Bearing Material      :      52100 Steel
Bore Diameter      :      1-1/4 in
Cage Material      :      Nylon
Closure Type      :      Double Seal
Finish      :      Chrome Steel
Load Capacity      :      2620 lb
Maximum Speed      :      5000 rpm
Number of Rows      :      1
Outside Diameter      :      2-9/16 in
Series      :      7500®
Temperature Rating      :      300 deg F
Type      :      Heavy Duty Non-Fill Slot
Width      :      3/4 in
  • Precision ground on all contact surfaces, similar to the 1600® series bearings
  • Highly effective single lip contact seal with trash guard
  • Precision ground on all surfaces and ball grooves for smooth rotation and easy installation
  • Pregreased with metered Shell Alvania #2 grease
  • Recommended for applications where accurate, quiet performance and superior sealing are required
  • 5360 lb dynamic/2620 lb static
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nice_40014VBF53_Catalog.pdf
