Martin R1 55MM MARR155MM
Martin R1 55MM MST Bushing, 55 mm Dia Bore, 3-7/8 in Small End/4 in Large End Dia Barrel, 5-3/8 in Dia Flange, 2.88 in OAL, Ductile Iron
- Manufacturer: Martin Sprocket & Gear
- Brand Name: Martin
- Part Number: MARR155MM
- MPN: R1 55MM
- UPC: 697950817309
- Min. Order Qty: 1
- Qty. Interval: 1
- Sign In for Pricing and Availability
- Sold As: 1/EA
-
Price:
MST® bushings are easy to install and remove. They are split through the barrel and have a taper to provide a true clamp on the shaft. They are keyed to both the shaft and the hub to help during "blind" installations.
Martin MST Bushing, 55 mm Bore Dia, 3-7/8 in Small End/4 in Large End Barrel Dia, 5-3/4 in Hub Dia, 4-5/8 in Bolt Circle, 5-3/8 in Flange Dia, 5/8 in Flange Thickness, 3 Bolt Holes, 3/8-16 x 1-3/4 in (Cap Screw)/5/16-18 x 5/16 in (Set Screw) Screw, For Use With: MST® Sprockets and HR1 Weld-On Hub, 2.88 in Overall Length, 16 x 4.3 in Keyway, Ductile Iron
| Barrel Diameter | : | 3-7/8 in Small End/4 in Large End |
| Bolt Circle Diameter | : | 4-5/8 in |
| Bore Diameter | : | 55 mm |
| Flange Diameter | : | 5-3/8 in |
| Flange Thickness | : | 5/8 in |
| Hub Diameter | : | 5-3/4 in |
| Keyway Size | : | 16 x 4.3 in |
| Material | : | Ductile Iron |
| Number of Bolt Holes | : | 3 |
| Overall Length | : | 2.88 in |
| Screw Size | : | 3/8-16 x 1-3/4 in (Cap Screw)/5/16-18 x 5/16 in (Set Screw) |
| Suitable For Use With | : | MST® Sprockets and HR1 Weld-On Hub |
- Size 1/R1 bushing
- Tolerances meet or exceed industry guidelines and standards
- Recommended for use with split taper bushed parts
- Precise machining and processes ensure consistent finish and high quality
- Interchangeable with other manufacturers’ split-taper bushings
