Martin HR1 MARHR1

Martin HR1 MST® Bushed Weld-On Hub, 4 in Bore, 5-3/4 in OD, 4-5/8 in Bolt Circle Diameter, 2 in OAL, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MARHR1
  • MPN: HR1
  • UPC: 697950219592
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Weld on hubs are suitable for use in many applications, such as welding to plate steel sprockets. They are made of steel, taper bored, drilled and tapped to accept various bushings.

Martin Weld-On Hub, MST® Bushed, 4 in Bore Dia, 5-3/4 in Outside Dia, 5-5/8 in Pilot Dia, 4-5/8 in Bolt Circle Dia, 3 Bolt Holes, 2 in Overall Length, Steel

Bolt Circle Diameter      :      4-5/8 in
Bore Diameter      :      4 in
Material      :      Steel
Number of Bolt Holes      :      3
Outside Diameter      :      5-3/4 in
Overall Length      :      2 in
Pilot Diameter      :      5-5/8 in
Type      :      MST® Bushed
  • Used to adapt components for split-taper bushings
  • Tolerances meet or exceed industry standards
  • Precise machining and processes ensure consistent finish and high quality
