Martin E60Q27H MARE60Q27H
  1. pin-int

Martin E60Q27H MARE60Q27H

Martin E60Q27H Type 25 Triple Strand Solid Bushed Roller Chain Sprocket With Hardened Teeth, 0.75 to 2.688 in Dia Bore, 6.867 in OD, #60 Chain, 27 Teeth, 3/4 in Pitch, Steel

  • Manufacturer: Martin Sprocket & Gear
  • Brand Name: Martin
  • Part Number: MARE60Q27H
  • MPN: E60Q27H
  • UPC: 697950218847
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading
  • Sign In for Pricing and Availability

Martin split taper sprocket is another style of bushed sprocket. The split taper bushing, when installed, offers a wide range of bore sizes.

Martin Roller Chain Sprocket, Type 25 Triple Strand Solid Bushed, 0.75 to 2.688 in Bore, 6.867 in OD, #60 Chain, 27 Teeth, 3/4 in Pitch, 6.4603 in Pitch Diameter, 1/2 in Keyway, 2.232 in Length Through Bore, MST® Q1 Bushing, Steel

Bore Diameter      :      0.75 to 2.688 in
Bushing Type      :      MST® Q1
Chain Size      :      #60
Keyway Size      :      1/2 in
Length Through Bore      :      2.232 in
Material      :      Steel
Number of Teeth      :      27
Outside Diameter      :      6.867 in
Pitch Diameter      :      6.4603 in
Pitch      :      3/4 in
Type      :      Type 25 Triple Strand Solid Bushed
  • Interchangeable with other manufacturer's split-taper bushings
  • Precise machining and processes ensure consistent finish and high quality
  • Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
  • Bores are concentric to pitch line, minimizing run out
