Martin D16C60 MARD16C60

Martin metric double strand solid construction sprockets have proper spacing between chain rows. The sprockets are manufactured from high carbon steel. Martin does not stack "A" plates on multiples, but instead Martin machines teeth after the chain rows are already in place. These plain bore sprockets can easily be bored to a metric or standard size to fit your application. Keyways, set screws and harden teeth are quick alterations that can be made.

Martin Roller Chain Sprocket, Type C Double Strand Stock Bore Welded, 40 to 95 mm Bore, 499.872 mm OD, #16B-2 Chain, 60 Teeth, 25.4 mm Pitch, 485.33 mm Pitch Diameter, 145 mm Diameter Hub, 95 mm Length Through Bore, High Carbon Steel

• Without hardened teeth

• Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Martin_D06B114_Specification_Sheet.pdf
